BCC Color Correction

Category: BCC Color & Tone

Effect Name: BCC Color Correction

The BCC Color Correction filter improves, part of the BCC Color & Tone category, the color of images or creates dramatic color effects.

Working with the Filter

Presets and Common Controls

• BCC filters come with a library of factory installed presets plus the ability to create your own custom presets and preview them with the BCC FX Browser™.
• BCC filters also include common controls that configure global effect preferences and other host-specific effect settings.

For more information about working with presets and other common controls, Click Here.

Effect Controls

Mocha Mask and Track

Continuum effects include integrated masking and matte tools that allow you to restrict the effect to specific regions of the image.

• Mocha masks: used to create custom spline masks. Mocha also includes Matte Assist ML and Matte Refine ML, which use machine learning to generate and track masks.
• Pixel Chooser: used to generate geometric shapes, gradients, or mattes based on channel, luma, or color-based selections. Additionally, an AI depth map generator, and an AI-powered face detection model allow for precise control of masks and mattes.

For more information, see Mocha and Pixel Chooser.

Compare Mode

The Compare Mode is used to view the filtered result alongside the original source layer. Several split-screen and side-by-side display options are available.

For more information, see Compare Mode.

Beat Reactor

The Beat Reactor is an audio-driven animation system that links effect parameters to an audio track. This allows visual effects to react dynamically to sound without manual key-framing.

For more information, see Beat Reactor Documentation.

• Brightness: Sets the brightness of the image.
• Contrast: Sets the contrast of the image.
• Color Space: Select various color space models to work with.
• Legacy
• HSI: Hue, Saturation, Intensity color space.
• HSL: Hue, Saturation, Lightness color space.
• HSV: Hue, Saturation, Value color space.
• HSP: Hue, Saturation, Perceived Brightness color space.
• HSLuma: Hue, Saturation, Luma color space.
• Hue: Adjusts the colors in the image around the color wheel in HSL color space.
• Hue Fine Control: Fine tunes the Hue parameter in increments of 1.
• Saturation: adjusts the intensity of each color’s hue in the image. Negative values remove color from the image, and positive values add color to the image.
• Output Black: adjusts the luminance level of black pixels. Increasing Output Black from its default value of 0 makes black pixels brighter and pushes the RGB color space toward white.
• Output White: adjusts the luminance level of white pixels. Decreasing Output White from its default of 255 makes white pixels darker and pushes the RGB color space toward black.
• Mix with Original: Blends the source and filtered images. Use this parameter to animate the effect from the unfiltered to the filtered image without adjusting other settings, or to reduce the effect of the filter by mixing it with the source image.
